GestureDashboard
Monitor and control your gesture recognition engine in real time.
--
Gestures
--
FPS
--
Status
Install GestureV
Copy the commands below into Command Prompt to install.
winget install Git.Git --accept-source-agreements --accept-package-agreements --silent
winget install Python.Python.3.12 --accept-source-agreements --accept-package-agreements --silent
powershell -Command "$env:Path = [System.Environment]::GetEnvironmentVariable('Path','Machine') + ';' + [System.Environment]::GetEnvironmentVariable('Path','User')"
git clone https://github.com/SuperduperCoders/GestureV.git "%USERPROFILE%\GestureV"
cd "%USERPROFILE%\GestureV"
python -m venv .venv
.venv\Scripts\pip install -r requirements.txt
.venv\Scripts\python controller.py
Open Command Prompt, paste all commands, and press Enter. If Python is not found after installing, close and reopen Command Prompt, then run only the last 5 commands.
System Performance
CPU0%
Memory0 MB
FPS0
Uptime0m
Quick Settings
Quick Actions
Supported Gestures
Live Activity
Waiting for gesture events...
Keyboard Shortcuts
1-4
Switch pages
Esc
Go to Dashboard
Ctrl+K
Command Palette
In video: q
Quit controller
Quick Gesture Reference
Point
Move mouse
Pinch
Left click
Open Palm
Mouse ON
Fist
Mouse OFF
Thumbs Up
Enter
Smile
Space
Bindings
Assign actions to each gesture. Your changes are saved immediately.
Help & Guide
Everything you need to know about GestureV — from setup to advanced customization.
Quick Start
1
Install Python & GitRun the install commands from the Dashboard, or install Python 3.12+ and Git manually.
2
Clone & install dependenciesOpen Command Prompt, paste the install commands from the Dashboard. This clones the repo, creates a virtual environment, and installs all packages.
3
Launch the controllerRun .venv\Scripts\python controller.py or double-click GestureV.bat. A calibration screen will appear — look straight at the camera for ~2 seconds.
4
Start making gesturesPoint your index finger to move the mouse. Pinch to click. Use hand gestures and facial expressions to trigger actions. A green dot in the top-left means mouse control is active.
5
Press q in the video window to quitThe controller window will close and all gesture detection stops.
Startup Calibration
!
The controller needs to learn your neutral face before startingDuring calibration, a circular progress bar appears. Look straight at the camera with a relaxed face. The system measures your default eyebrow position. Calibration takes about 2 seconds. If it times out after 8 seconds, a default value is used. Poor calibration = poor face gesture detection.
Mouse Control
Point
Move cursor
Pinch
Left click
Open Palm
Mouse ON
Fist
Mouse OFF
Point + Pinch
Drag
Two Fingers
Scroll
Hand Gestures
Swipe L/R/U/D
Arrow keys
Thumbs Up
Enter
Peace Sign
Screenshot
Rock On
Play/Pause
Thumb + Pinky
Volume
Clap
YouTube
Facial Gestures
Smile
Space
Wink Left
Left arrow
Wink Right
Right arrow
Eyebrow Raise
Down arrow
Head Nod
Enter
Head Shake
Escape
Customizing Bindings
1
Go to the Bindings page from the sidebarYou can also edit gesture_bindings.json directly in the project folder.
2
Choose a binding typeAvailable types: key (single key), hotkey (key combo like ctrl+alt+s), url (open a website), type (type text), or app (launch an application).
3
Set the action valueFor key: key name (e.g. space, enter). For hotkey: combo (e.g. ctrl+alt+s). For url: full URL. For app: app path or name.
4
Toggle gestures on/offUse the toggle switch to enable or disable any gesture without deleting its binding.
5
Save — changes apply immediatelyThe controller reloads bindings automatically. No restart needed.
Keyboard Shortcuts
1 / 2 / 3 / 4
Switch pages
Esc
Back to Dashboard
/ or Ctrl+K
Search gestures
Troubleshooting
!
Mouse moves erratically or jumpsImprove lighting, face the camera directly, and ensure your hand is clearly visible. Try enabling Cursor Smoothing in Quick Settings to reduce jitter.
!
Face gestures not detectingMake sure Face Detection is enabled in Quick Settings. Check that your face is well-lit and centered. Re-calibrate by restarting the controller.
!
"Python was not found" after installingAfter winget installs Python, the current terminal session doesn't see it yet. Close Command Prompt and reopen it, then run only the last 5 commands (from git clone onwards). The commands on the Dashboard already include a PATH refresh command to handle this automatically.
!
Controller won't startCheck that Python 3.12+ is installed and in your PATH. Make sure you've activated the venv (.venv\Scripts\activate) and installed requirements (pip install -r requirements.txt). Check controller.log for errors.
!
Camera not foundEnsure your webcam is connected and not in use by another app. Check Windows Privacy Settings → Camera → allow desktop apps to access your camera.
!
Gestures are delayedClose other applications using the camera or heavy CPU. Reduce the camera resolution in config.py. Check the FPS counter on the Dashboard — aim for 30+ FPS.
Frequently Asked Questions
Q
Does GestureV work on Mac or Linux?Currently, GestureV is Windows-only. It uses pyautogui and Win32 APIs for mouse/keyboard control. Linux support is planned for a future release.
Q
Is my webcam data sent anywhere?No. All processing happens locally on your machine. Nothing is uploaded, streamed, or stored. GestureV runs 100% offline.
Q
Can I use GestureV without a webcam?No. GestureV requires a webcam to detect hand and facial gestures. Any standard USB webcam works.
Q
How do I update GestureV?Pull the latest changes with git pull in the project folder, then re-run pip install -r requirements.txt in case new dependencies were added.
Q
Can I run the tracker in a browser instead?Yes! Run python dashboard.py and open the dashboard. The browser-based tracker uses MediaPipe JS and sends commands to the Python agent.
Tips for Best Results
Good lighting
Face a light source
Center yourself
Face the camera directly
Clear background
Less clutter behind you
Hold gestures
Steady for ~0.5s
Clean lens
Wipe your camera
Close background apps
Free up CPU & camera
Still Need Help?
Check controller.log for debugging info. Join our community or open an issue on GitHub.
